In the image below, note how we want to choose to create a Stair Run (1) and we want a simple straight Run (2)- as opposed to a Spiral Stair, etc. When you hit the “Stair” tool, Revit immediately switches to Sketch Mode.
We are going to create a Stair that starts at Level 0 and goes up to Level 1……įirst of all select the “Architecture” menu and then the “Stair” tool, which can be found on the “Circulation” panel… If I switch to an elevation view you can see that there are 3 Levels in the model. We now have something in which to create our Stairs. Just to make the tutorial a little more realistic I have created a simple building shell. In this Revit Architecture tutorial I show you the basic operation of the “ Stair by Component” tool.
